I want to plot a graph and keep it even if the script finished. But it failed after I tried many times.

After script finished executing, the graph created by the show() method will be closed simultaneously.

Code:

import matplotlib.pyplot as plt plt.scatter([0], [1]) plt.draw() plt.show(block=False) for i in range(10): plt.scatter([i], [i+1]) plt.draw() plt.pause(0.001)

My version is below:

user@ya:~/$ sudo pip freeze | grep matplotlib matplotlib==2.2.3 user@ya:~/$ sudo pip -V pip 18.1 from /usr/local/lib/python2.7/dist-packages/pip (python 2.7)

Environments:

I only execute script in Ubuntu ex: user@ya: python xxx.py Distributor ID: Ubuntu Description: Ubuntu 16.04.5 LTS Release: 16.04 Codename: xenial

Can anyone help me? I just want to do like Matlab which won't close the plotted graph even if the script finishes.

1 Answer

This is more a question for stackoverflow.com that askubuntu.com

Anyway, the fix is simple. You called plt.show() with block=False. So that's why it exists at the end of the script.

Just add a single line like:

plt.show()

at the end of your script and the plot will stay open.
